Use with caliper part number 270735.
# of Bolt Holes : 5
Bolt Circle Diameter : 4.25"
Brake Rotor Diameter : 10.71"
Brake Rotor Discard Thickness : .9"
Brake Rotor Thickness New : .95"
Brake Rotor Type : Disc Brake Rotor Only
Center Hole Diameter : 2.69"
Height : 2.91"
Maximum Lateral Runout : .004"
Vented / Solid : Vented
Mounting Type : Type K - Rotor Only. Wheel Studs Are Pressed Into The Hub Only.
The Rotor Is A Loose Fit On The Hub & Is Retained By Either Machine Screws Or The Wheel Nuts. See Diagram For More Information.

This part replaces part no 688950
